常用無線藍牙晶振FCX3M02600009E1D 3225 26M 9PF 10PP 香港富士Fuji晶振
藍牙,是一種支持設備短距離通信的無線電技術,這個距離一般是十米內.其用途包括無線耳機、筆記型電腦、行動電話、音箱、PDA等都用到石英晶振相關外設等眾多設備之間進行無線資訊交換.
Bluetooth is a radio technology that enables devices to communicate over short distances, usually within ten meters. It is used for wireless information exchange between many devices such as wireless headphones, notebook computers, mobile phones, speakers, PDAs and other related peripherals.
富士無源晶振,耳機晶振FCX-3M,進口晶振溫補晶振

利用藍牙級數,可以能夠有效地簡化行動通訊終端設備之間的通信,也可以成功地簡化設備與因特網之間的通信,使數據傳輸變得更加的迅速高效,為無線通訊拓寬了一條道路!富士晶振它是一種無線數據與語音通信的開放性全球規范,它可以拋開傳統的連線束縛,讓人們徹底地享受無拘無束的樂趣,這種便利是其他的設施和技術所不能夠滿足的.
The use of Bluetooth series can effectively simplify the communication between mobile communication terminal equipment, can also successfully simplify the communication between the device and the Internet, so that the data transmission becomes 進口晶振more rapid and efficient, and broadens a road for wireless communication! It is an open global norm for wireless data and voice communication, which can throw away the shackles of traditional connectivity and allow people to thoroughly enjoy unfettered fun, which is not able to meet other facilities and technologies.富士無源晶振,耳機晶振FCX-3M,進口晶振壹兆電子

IC Brand	IC Number	Package size	FCom Series	Frequency
CSR	CSR1010	2520 SMD-4	FCX-2M	16 MHz
CSR	CSR1010	3225 SMD-4	FCX-3M	16 MHz
CSR	CSR8510	3225 SMD-4	FCX-3M	26 MHz
CSR	CSR8510	3225 SMD-4	FCX-3M	26 MHz
DME	DME_1080	HC-49SMD-2	FCX-9M	16 MHz
Nordic	nRF51822	HC-49SMD-2	FCX-9M	16 MHz
Nordic	nRF52810-QFAA	3215 SMD-2	FCT-3M	32.768 KHz
Nordic	nRF52810-QFAA	3225 SMD-4	FCX-3M	32 MHz
Nordic	nRF52810	3225 SMD-4	FCX-3M	32 MHz
Qualcomm	CSR1010	2016 SMD-4	FCX-2S	16 MHz
Qualcomm	CSR1010	3225 SMD-4	FCX-3M	16 MHz
Qualcomm	QCC5124	2016 SMD-4	FCX-2S	32 MHz
Remoteble	RT400	3225 SMD-4	FCX-3M	12 MHz
Remoteble	RT400	HC-49SMD-2	FCX-9M	12 MHz
TI	CC2541-Q1	3215 SMD-2	FCT-3M	32.768 KHz
TI	CC2541-Q1	3225 SMD-4	FCX-3M	32 MHz
TI	CC2541	3225 SMD-4	FCX-3M	32 MHz
TI	CC2564	2016 SMD-4	FCX-2S	26 MHz
TI	CC2564	2016 SMD-4	FCX-2S	38.4 MHz
TI	CC2564	3215 SMD-2	FCT-3M	32.768 KHz
TI	CC2564	3225 SMD-4	FCX-3M	26 MHz
TI	CC2564	3225 SMD-4	FCX-3M	38.4 MHz
TI	CC2640	2016 SMD-4	FCX-2S	24 MHz
TI	CC2640	3215 SMD-2	FCT-3M	32.768 KHz
TI	CC2640	3225 SMD-4	FCX-3M	24 MHz

藍牙所能用到的貼片晶振有常用頻率有3225 12MHZ、3225 16MHZ、3225 24MHZ、3225 26MHZ、3225 32MHZ等,一般比較常用的是3225 26M.藍牙晶振負載電容有7PF、9PF、12PF、20PF其中9PF的負載最為廣泛.頻率精確度(頻率誤差)也是KDS晶振很重要的一個參數,目前市場流通的有±10PPM、±20PPM和±30PPM,±10PPM最為穩定可靠,Fuji Crystal的高精度晶振可完美的配合藍牙實現無損傳輸.
The chip crystal oscillator used by Bluetooth has a common frequency of 3225 12MHZ, 3225 16MHZ, 3225 24MHZ, 3225 26MHZ, 3225 32MHZ, and so on, and the most commonly used is 3225 26M. Bluetooth crystal load capacitors are 7PF, 9PF, 12PF, 20PF, of which 9PF has the most extensive load. Frequency accuracy (frequency error) is also a very important parameter of Crystal oscillator, the current market circulation is ±10PPM,± 20PPM and ±30PPM,±10PPM is the most stable and reliable,Fuji Crystal's high-precision crystal oscillator can perfectly cooperate with Bluetooth to achieve lossless transmission.
富士無源晶振,耳機晶振FCX-3M,石英晶體振蕩器,進口晶振
